Specifications
| Technical Parameters | |
|---|---|
| Working voltage rating | 3.5~6.5V |
| Working pulse width rating | 70~320Ms |
| Rated working pulse interval | ≥ 50MS |
| Coil resistance | 430± 5%ohm23± 2 |
| Velocity ratio | 200: 1 |
| Working frequency | 6Hz |
| Step motor driving torque | 30 u Nm |
| Character wheel material | PC |
| Range of working ambient temperature | 40o C~+70o C |
| Lead length | 90mm, 100mm or 120mm |
| Error-free working period | ≥ 10years |
| Base frame material: Plastic base frame | PC |
